Additional information
More
| METHANE | 150 / 45 |
|---|
Key Facts
| RESPONSE TIME | Typically 5 seconds |
|---|---|
| CABLE ENTRY | 2 × 3/4″ – 14NPT or 2 × M25 × 1.5 mm |
| FLAMEPROOF | ✓ |
| INCREASED SAFETY | ✓ |
| SIL | ✓ (SIL 2) |
| 4-20 MA | ✓ |
| HART® | ✓ |
| FIELD OF VIEW | Horizontal 100°; Vertical 95° |
| DETECTION TECHNOLOGY | IR3 |
| RS-485 | ✓ |
| RELAY | ✓ |
Technical Data
| FIELD OF VIEW | Horizontal 100°; Vertical 95° |
|---|---|
| WEIGHT | 2.8 Kg |
| DEGREE OF PROTECTION | IP66/67 |
| POWER SUPPLY | 24 V DC |
| TEMPERATURE (OPERATION) | -55°C – 75°C |
| HUMIDITY | 0 to 95 % r.h., non-condensing |
| HOUSING MATERIAL | Stainless steel SS 316 or Heavy duty copper free aluminum, red epoxy enamel finish |
| DIMENSIONS (H × W × D) | 0.1×0.12×0.16 m |
Fuel ft / m
| N-HEPTANE / GASOLINE | 215 / 65 |
|---|---|
| DIESEL FUEL / JP5 / KEROSENE | 150 / 45 |
| ETHANOL 95 % | 135 / 40 |
| METHANOL | 115 / 35 |
| IPA (ISOPROPYL ALCOHOL) | 135 / 40 |
| LPG | 150 / 45 |
| POLYPROPYLENE PELLETS | 115 / 35 |
| OFFICE PAPER | 83 / 25 |
Approvals
| ATEX | ✓ |
|---|---|
| IECEX | ✓ |
| GOST (EAC) | ✓ |
| PERFORMANCE APPROVAL | ✓ |
| SHIPPING APPROVAL | ✓ |
| UL | ✗ |
| CSA | ✓ |
| FM | ✓ |
| CE MARKING | ✓ |
