Additional information
Key Facts
| FIXED TYPE | Transmitter |
|---|---|
| CABLE ENTRY | M20 or 3/4″ NPT |
| DISPLAY | Yes |
| INTRINSIC SAFETY | Νο |
| FLAMEPROOF | Yes |
| INCREASED SAFETY | Yes |
| SIL | No |
| 4-20 MA | Yes |
| BUS | Yes |
| HART® | Yes |
| WIRELESS | No |
Technical Data
| DISPLAY | Yes |
|---|---|
| WEIGHT | 4 Kg |
| DIMENSIONS (W × H × D) | 0.28×0.15×0.13 m |
| DEGREE OF PROTECTION | IP65/66/67 |
| POWER SUPPLY | 10 to 30 V DC, 3-wire |
| TEMPERATURE (OPERATION) | -40°C – 65°C |
| HUMIDITY | 0 to 100 % r.h., non-condensing |
| PRESSURE (HPA) | 700 – 1300 |
| HOUSING MATERIAL | Epoxy coated copper-free aluminum or stainless steel SS316 L |
Approvals
| ATEX | Yes |
|---|---|
| IECEX | Yes |
| CE | Yes |
| GOST (EAC) | Yes |
| PERFORMANCE APPROVAL | Yes |
| SHIPPING APPROVAL | Yes |
| UL | Yes |
| CSA | Yes |
| FM | No |
