DRÄGER CPS 7800

The reusable gas-tight Dräger CPS 7800 provides excellent protection against gaseous, liquid, aerosol and solid hazardous substances even in explosive areas.

Due to its innovative material and the new suit design it offers increased flexibility and comfort when entering confined spaces and working with cryogenic substances.

Benefit

Gas-tight suit

  • ​SCBA worn over the protective suit
  • five suit sizes (S-XXL)
  • diagonal zipper for easy donning and doffing without assistance
  • suit material D-mex, reusable

Reliable protection

The Dräger CPS 7800 (Typ 1b) protects against a multitude of possible dangers when dealing with hazardous substances. The novel antistatic material D-mex offers excellent chemical resistance and protection against mechanical influences. The Dräger CPS 7800 exceeds the requirements of international industry standards for reusable protective suits
D-MEX: 5-Fold safety

D-mex, the unique suit material, consists of five layers and its reliability has been proven during hazardous substance deployments by the fire service. Tear-proof textile forms the middle layer; on the inside and outside there is a particularly robust elastomer layer, as well as a chemically high-resistant barrier layer. With this design, the suit retains its full protection performance even if the outer material is damaged.
Fitted, flexible and comfortable

The Dräger CPS 7800 increases the wearing comfort even during difficult work in hazardous areas. With its ergonomic cut and five sizes to choose from it offers the highest degree of flexibility for wearers ranging from 1.50 m to 2.05 m in height. In addition, the light and soft suit material adapts ideally for a full range of movement. Offered as an option, individually adjustable braces provide even greater wearing comfort to the user and an improved fit of the suit. A newly designed fit means you don the Dräger CPS 7800 with more ease, can put on and remove the suit by yourself, and shut the zip fasteners without assistance.
Always ready

Time and expense for regular testing could be reduced significantly through innovative materials and new service concepts. The suit can also be cleaned and disinfected automatically without complications. This reduces the effort required to keep the suit ready for use over its lifetime of up to 15 years. An unused suit with face cuff can even be stored for five years without servicing. If repair or maintenance is required, this can be performed by the service technician. Of course, DrägerService is equally happy to perform these tasks.
Ready for the extraordinary

With optional accessories, the Dräger CPS 7800 can be adapted to be even more individual to meet your specific requirements and in turn extend your deployment options further. The suit is available with an integrated Panorama Nova full face mask or face cuff. Stress reduction, especially during prolonged use, can be achieved by equipping the suit with ventilation systems. The Dräger CPS 7800 features an optional ventilation system with the integrated regulating valve PT 120 L that can be connected to different breathing air sources. The suit can also be printed with a customer-specific design, if desired. The Dräger CPS 7800 training suit permits you to perform exercises in realistic scenarios outside contaminated areas with the same equipment characteristics.

Additional Information

More

EN ISO 13982-1

Resistance against

Particles
Liquids
Known gases
Unknown gases
Mechanical stress
Deepcold substances ✓ Depending on SCBA
Ex-zones ✓ Depending on SCBA
Flash fires ✓ Depending on SCBA

Resistance

Mechanical Resistance ++
Chemical Resistance ++
Temperature Resistance ++

Key Facts

Product Type Gas-tight suit
Reuse Class Reusable
Suit Type Class 1
Performance Class +++
SCBA design outside
Shelf Life (years) 15
Material D-mex™
Available Colors Blue, Orange

Approvals

EN 1073-1 / EN 1073-2
EN 943
EN 14605
EN 13034
EN 14126
EN 1149
EN 14593
EN 14594
SOLAS
ISO 16602
